Universal Motor Speed Control

Universal Motor Speed Control

Universal Motor Speed Control

Categories: Educational Lab Trainers Lits

Object: To perform the following experiments : Half wave controller without feed back Half wave controller with feed back Half wave controller high torque at low speed version - skip cycling opera...

Product Code: AEET060

  • ISO Certified
  • 24x7 Support
  • High Quality
  • After Sales Service
Product

About this product

Object: To perform the following experiments :
  • Half wave controller without feed back
  • Half wave controller with feed back
  • Half wave controller high torque at low speed version - skip cycling operation
  • Full wave controller using triac and demonstrating hysteresis effects improved  by gate slaving techniques
Features: The board consists of following built-in parts: 1. SCR and TRIAC for the speed control of the universal motor. 2. Two potentiometers. 3. Two capacitors to control firing angle of thyristors. 4. DIAC and two Nos. of diodes. 5. A Universal motor of 1/12 H.P. or less capacity. 6. Snubber circuit in parallel with the triac, which helps in improving the Dv/Dt of the device and also helps in reducing the RFI. 7. Adequate no. of other Electronic Components. 8. Mains ON/OFF switch, Fuse and Jewel light.
